Walkeh; Irancell’s push to talk system
This service allows users to have a voice or multimedia conversation
directly with each other by pressing and holding a button.
Service introduction
Irancell’s push to talk over cellular system provides a communication platform for non-synchronous, dial-free calls between sender and receiver, enabling users to make direct voice or multimedia (video, images, and messages) calls by simply pressing and holding a button. Through this solution, calls are established without delay over Irancell’s secure network, ensuring fast message exchanges. Walkeh supports both one-to-one and one-to-group communications through dedicated push-to-talk terminals.
The high security and ability to establish calls quickly without dialing make Walkeh an ideal solution for users who require speed, security, and reliability in their voice and multimedia communications. This solution can be applied to a wide range of industries, including:
- Logistics
- Transportation industry, airports, railways
- Security and surveillance
- Commercial complexes, shopping malls, hotels
- Ports and public parking lots
- And more
Benefits and Features of Walkeh; Irancell’s push to talk over cellular system
Secure one-to-one or one-to-group calls without the need to dial, simply by pressing a button
Sending and receiving text messages
Elimination of location restrictions and operable wherever Irancell’s nationwide network is available
No need to obtain a frequency license from the Radio and Communications Regulatory Authority
The ability to send an SOS message with a single button press and automatically activate a two-way voice call
Logging all calls, including voice, video, and text communications
A user and group control center with special features (central dispatching system)
GPS capability for tracking workgroups on an online map
Real-time and secure transmission of live video, messages, and images to individuals or groups
Creating secure organizational groups to prevent information leaks
Establishing specialized workgroups in specific geographical areas to align operational goals during crises
No need to set up a new and dedicated network, leveraging Irancell’s broadband network coverage
Comparison Table
You can check and compare the features of each model in the table below
Features:
Model PNC380
Model PNC460
Model MNC360
Memory
-
4 GB RAM + 64 GB ROM
1GB RAM + 8GB ROM
LTE Band
B1 / B3 / B5 / B7 / B8 / B20
B1 / B3 / B5 / B7 / B8 / B20 / B26 / B28 / B34 / B38 / B39 / B40 / B41
B1 / B2 / B3 / B4 / B5 / B7 / B8 / B12 / B13 / B17 / B20 / B26 / B27 / B28 / B38 / B39 / B40 / B41
Camera
5Mp Rear
Front: 8MP, Rear: 50MP
-
OS
Android 7.1
Android 12
Android 7.1
SIM Card
Nano SIM (12x9mm)
2 x Nano SIM (12x9mm)
2 x Micro SIM
Dimensions (H x W x D)
145 x 60 x 26 mm
164 x 77 x 14 mm
170 x 66 x 39.3 mm
Weight (with Battery)
200g
275g
300g
Display
2.0 inch (color TFT 320x240)
5.0-inches FHD Touch
2.0 inches
Port
Micro USB 2.0, 3.5mm Audio Jack
USB type-C
Micro USB
Battery Life
4000mAh (Li-ion),≥20h (5-5-90 duty cycle)
4500mAh (Li-ion), ≥20h (5-5-90 duty cycle)
-
Speaker
1W(Rated), 2W(Max)
3W Dual Speaker
4W
WLAN
2.4GHz, 802.11 b/g/n
2.4GHz, 5GHz
2.4GHz,802.11 b/g/n
Bluetooth
BT4.1
BT5.0
BT4.2
Positioning
GPS / AGPS / BDS / GLONASS
GPS / AGPS / BDS / GLONASS / Galileo
GPS / AGPS / BDS / GLONASS
Dust & Water Proof
IP67
IP68
IP54
Shock & Vibration
MIL-STD-810 G
MIL-STD-810H
MIL-STD-810H
Drop Resistance
1.2m
1.5m
1.2m
Operation Temperature
-20℃~+60℃
-20℃~+60℃
-20℃~+60℃
Storage Temperature
-30℃~+70℃
-30℃~+70℃
-40℃~+85℃
Standard
-
IEC 61000-4-2 Electromagnetic compatibility (EMC)
FCC/IC/CE
Attributes:
Memory:
-
LTE Band:
B1 / B3 / B5 / B7 / B8 / B20
Camera:
5Mp Rear
OS:
Android 7.1
SIM Card:
Nano SIM (12x9mm)
Dimensions (H x W x D):
145 x 60 x 26 mm
Weight (with Battery):
200g
Display:
2.0 inch (color TFT 320x240)
Port:
Micro USB 2.0, 3.5mm Audio Jack
Battery Life:
4000mAh (Li-ion),≥20h (5-5-90 duty cycle)
Speaker:
1W(Rated), 2W(Max)
WLAN:
2.4GHz, 802.11 b/g/n
Bluetooth:
BT4.1
Positioning:
GPS / AGPS / BDS / GLONASS
Dust & Water Proof:
IP67
Shock & Vibration:
MIL-STD-810 G
Drop Resistance:
1.2m
Operation Temperature:
-20℃~+60℃
Storage Temperature:
-30℃~+70℃
Standard:
-
Attributes:
Memory:
4 GB RAM + 64 GB ROM
LTE Band:
B1 / B3 / B5 / B7 / B8 / B20 / B26 / B28 / B34 / B38 / B39 / B40 / B41
Camera:
Front: 8MP, Rear: 50MP
OS:
Android 12
SIM Card:
2 x Nano SIM (12x9mm)
Dimensions (H x W x D):
164 x 77 x 14 mm
Weight (with Battery):
275g
Display:
5.0-inches FHD Touch
Port:
USB type-C
Battery Life:
4500mAh (Li-ion), ≥20h (5-5-90 duty cycle)
Speaker:
3W Dual Speaker
WLAN:
2.4GHz, 5GHz
Bluetooth:
BT5.0
Positioning:
GPS / AGPS / BDS / GLONASS / Galileo
Dust & Water Proof:
IP68
Shock & Vibration:
MIL-STD-810H
Drop Resistance:
1.5m
Operation Temperature:
-20℃~+60℃
Storage Temperature:
-30℃~+70℃
Standard:
IEC 61000-4-2 Electromagnetic compatibility (EMC)
Attributes:
Memory:
1GB RAM + 8GB ROM
LTE Band:
B1 / B2 / B3 / B4 / B5 / B7 / B8 / B12 / B13 / B17 / B20 / B26 / B27 / B28 / B38 / B39 / B40 / B41
Camera:
-
OS:
Android 7.1
SIM Card:
2 x Micro SIM
Dimensions (H x W x D):
170 x 66 x 39.3 mm
Weight (with Battery):
300g
Display:
2.0 inches
Port:
Micro USB
Battery Life:
-
Speaker:
4W
WLAN:
2.4GHz,802.11 b/g/n
Bluetooth:
BT4.2
Positioning:
GPS / AGPS / BDS / GLONASS
Dust & Water Proof:
IP54
Shock & Vibration:
MIL-STD-810H
Drop Resistance:
1.2m
Operation Temperature:
-20℃~+60℃
Storage Temperature:
-40℃~+85℃
Standard:
FCC/IC/CE
FAQs
Depending on the model, push to talk systems use technologies such as DMR, PMR, MCPTT, and iDEN. Walkeh utilizes PoC (Push-to-Talk Over Cellular) technology, enabling Push-to-Talk services via Irancell’s network and mobile broadband.
Key benefits of PoC technology in Walkeh include:
- Call and communication logging
- Centralized user and group control with special features
- GPS tracking of workgroups on an online map
- Secure real-time transmission of live videos, messages, and images, person-to-person or in a group
- Creating secure organizational groups to prevent communication leaks
- Establishing specialized geographical workgroups during crises and converging operational goals
- Operating on Irancell’s nationwide broadband network without requiring new network setups
Irancell’s push to talk over cellular system is available in any region covered by Irancell’s nationwide data network. Basic PTT services require minimal bandwidth, while video and image transmission needs higher and stable bandwidth.
The necessary equipment depends on the specific needs of the customer. Generally, push to talk terminals must be provided for each employee intending to use this service. These terminals come in various models with different features and are equipped with a dedicated Walkeh SIM card.
This system operates on Irancell’s secure mobile network, meeting all standard security requirements. Also, the TLS/SSL protocols are used in the Wakeh service layer, which increases its security.
No, due to the independent dedicated network established for the service and its lack of dependence on the internet, Irancell’s Walkeh service offers high stability.
Yes, if necessary and depending on the customer’s need to expand the existing network capacity using PoC technology, the Walkeh network can be connected to the customer’s existing network through appropriate gateways.
No, PoC terminals use specialized technologies unique to this network. Also, the applicants of this service must use the dedicated terminals to access Walkeh services.
To use the Wakeh service, customers need to purchase dedicated terminals and pay for:
- Voice and video subscription
- Subscription to the computer version of the dispatching system
- Installation and setup of the computer version of the dispatching system
Yes, by purchasing the appropriate license, the Wakeh service can provide a dispatching system that can be used on the organization’s computers.
Corporate customers can contact Irancell for more information via:
- Using the EMP system
- Sending an email to EB@mtnirancell.ir
- Dialing 714 from Irancell lines or 09377140000 from other lines
